70-D3B-2_CNP | SEWING MACHINE
MERROW 72-D3B-2_CNP SPECIFICATIONS
OPERATING SPEED |
2250 RPM |
STITCH WIDTH |
16MM (5/8") |
STITCH RANGE |
152.4 SPMM (6 SPI) |
STANDARD NEEDLE |
MERROW 8SDT |
MERROW NEEDLE RANGE |
MERROW 3SDT-8SDT |
FEDERAL STITCH TYPE |
503 |
STITCHES PER MM |
101MM - 305MM (4-12 SPI) |
NUMBER OF THREADS |
ONE THREAD |
"
Recommended Accessories
Details
The Merrow 70-D3B-2_CNP industrial sewing machine is designed to sew in harsh envi- ronments. It produces the same flat butted seam that has made the 70-D3B-2 the indus- try standard for end-to-end seaming, but has been chemically nickel plated (CNP) to allow for sewing on wet fabric. Chemically adhering the nickel to the machine offers the utmost protection from corrosion, and like all Merrow machines the 70-D3B-2_CNP is hand assembled with high quality steel parts, ensuring a perfect butted seam even after years of use.
Other Butt Seaming Machines
70-D3B-2
- IDEAL FOR DRY MATERIALS
- Most Durable Machine in the Industry
- THIN to MEDIUM WEIGHT FABRICS
72-D3B-2
- IDEAL FOR TUBULAR KNITS
- 3 Sets of Feed Dogs
- Extended Cutter Mechanism
- Longer Presser Foot!
70-Y3B-2
- Stitch Multiplying Butt Seamer
- For Strength at the selvages
- Lever Activated Stitch Multiplier
- Doubles the Stitch Count on Demand
72-D3B-R
- SEWS A ROLLED SEAM
- Ideal for loose knits
- Easy to Feed
70-D3B-2_LS
- NEW! TWO THREAD BUTT SEAMER
- Locking 5/8" Stitch
- Ideal for a TOUGH seam
70-D3B-2_HP
- For HIGH PILE fabrics
- Sews up to 2" thick material
- Used often for paint roller material, bed liners
70-D3B-2_RAIL
- the 70-D3B-2 for RAIL SETUPS
- Designed specifically for European and American Rail Systems
70-D3B-2_G
- A 5/8" stitch with a 1/4" GAP between fabric butts
- Ideal for SEAM DETECTION
- Allows for more flexibility with hard to sew goods
70-D3B-2_CNP
- the NICKEL PLATED MERROW 70-D3B-2
- Designed and Tested in WET environments
- Holds up to mercerizing, dyeing and bleaching
- Warrantied for 10 YEARS!!!
